1. Video:
Lub tshuab zeb CNC router no tseem muaj zog heev hauv kev ua haujlwm, thiab nws tuaj yeem txuas ntxiv mus kos tom qab fais fab tuag. Ua tiav 3 vib nas this riam teeb thiab lwm yam. Nws yog ib qho kev pab zoo rau cov chaw tsim khoom uas xav tau kev ua haujlwm ntau.
2. Daim ntawv thov:
1. Jade, amber, agate, daj zaj jade, pebbles thiab lwm yam mos jadeite, nrog rau iav, nyiaj, yas, hlau, ntoo thiab lwm yam khoom siv tes ua rau carving.
2. Yuav luag tag nrho cov nonmetals: txhua yam ntoo, khoom ntoo, xyoob, MDF, acrylic, PVC, organic iav, PCB, yas, ua npuas ncauj thiab lwm yam.
3. Hard nonmetals (xav tau dej-txias): ntuj marble, granite, bluestone, sandstone, dag pob zeb, tombstone, headstone, quartz pob zeb, milestone, memorial pob zeb, ceramics, ceramics, jade los yog jade pob zeb, siv lead ua, iav, txiv neej -ua marble thiab lwm yam.
4. Cov hlau mos (yuav tsum tau txiav cov kua dej-txias): tooj liab, tooj dag, aluminium composite panels, aluminium phaj, aluminium ntawv thiab txhuas qhov chaw.
3.Product Specification:
Tshuab Qauv | 4030A -4 Axis Pob Zeb CNC Router Tshuab |
X/Y/Z ncig teb chaws | 400 x 300 x 140 mm |
Dav Hlau Carving Loj (2D) | 270 x 100 x 140 mm |
Sculpture Carving Loj (3D) | Dia 100mmxLength 200mm |
Tus tswj | Hand Remote Controller |
Qhov hnyav | Yuav luag 350 kg |
Ncej | Integral cam khwb cia hlau, square steel bracket |
Tshuab Loj | 780x750x1700mm |
Carving thiab cov khoom ruaj txoj kev | Hloov ntoo platen thiab kua nplaum |
Engraving daws teeb meem | ±0.01 hli |
Spindle zog | 1.5KW High-speed water-cooled variable zaus spindle |
Spindle Rotating Ceev | 0-24000RPM |
Kev ceev ceev | 0-4000mm/min |
Qhia Rail | Ntshuam Square Rail |
Pob Ntsia Hlau | Imported Pob Ntsia Hlau |
Tsav Txoj Kev | Hybrid Servo |
Clampable Tool Shank Diameter | 2.3 hli / 3mm / 4mm / 6mm |
Tsim nyog ua hauj lwm voltage | AC220V, 50-60Hz |
Lub Tshuab Tag Nrho Lub Zog | 2.1 KW TSI |
lav | 18 Lub Hlis |
4.Product Advantages:
Peb yog cov kws tshaj lij hauv kev ua cov khoom siv jade carving.
4-Axis Linkage Technology 2D/3D Multifunction:
Txais yuav tshiab 4 axis CNC Controller, los daws qhov teeb meem ntawm cov nyhuv carving yog nruj, thiab tsis tas yuav kho nws.
Txhua yam ntawm cov hniav nyiaj hniav kub pendants nrog batch ua: ntau daim nruam carving ua
Peb qhov chaw ua haujlwm nrog 100mm txoj kab uas hla x 200mm ntev.
Cov nyhuv mute zoo, tsis cuam tshuam rau lub neej ib txwm muaj ntawm tsev neeg: Nws yog tag nrho cov qauv tsim ntawm lub rooj ua haujlwm nrog cov hlua khi ua ke kom txo cov suab nrov.
Kev tsim qauv pub dawb: tsuas yog rub tawm thiab siv ncaj qha rau ntawm lub tshuab CNC, yooj yim heev. Tus tsim cov duab tuaj yeem yog huab nws tus kheej rub tawm lossis peb muab kev pabcuam rau hard disk luam.
Qhov loj me thiab txav tau yooj yim: Patented tsos, kev sib xyaw me me tsim tsim, tsis nyob hauv pem teb, tsis tas yuav teeb tsa lwm lub txee hluav taws xob thiab khoos phis tawj, ib lub tshuab tuaj yeem ua haujlwm; nrog horizontally movable casters, ib tug neeg tuaj yeem txav tau yooj yim, uas yooj yim heev.
Engraving raug lub rooj: tuaj yeem kho qhov tseeb engraving.
1.5KW Zaus Dej Txias Spindle: txuag lub zog, ceev ceev, siab precision.
Txais Cov Nthuav Pob Ntsia Hlau: nrog ntau dua precision thiab ruaj khov.
5.Peb Kev Tsim Nyog:
6.Package rau xa:
Nrog dej-pov thawj pob ntawm lub tshuab dhos tshuab, thiab txheem exporting plywood ntoo rooj plaub.
7.FAQ:
Q1. Koj puas muaj kev pab cuam tom qab muag?
Peb muab kev pabcuam 24/7 thiab txhawb nqa ntawm email, hu, Skype lossis Whatsapp.
Q2. Koj puas muaj warranty thiab warranty?
Ib xyoo thiab ib nrab xyoo, thiab lub sijhawm no, yog tias koj muaj teeb meem, peb yuav daws nws dawb.
Q3. Lub sijhawm khoom xa tuaj yog dab tsi?
Tom qab PO tau lees paub ntawm ob sab, tsis pub dhau 7-20 hnub ua haujlwm rau kev xa khoom nrog lub thawv ntoo.
